WJ-80
| Availability: | |
|---|---|
The WJ-80 Middle Speed Paper bowl Machine is a multi station automatic machinery with automatic paper feeding, heat sealing into a cylinder, bowl top lubrication, punching and pressing the bottom of the bowl, heating and rolling the bottom of the bowl, upper edge curling, and finished product blowing. It is suitable for continuous processes such as single and double-sided film cooling, hot beverage paper bowls, ice cream bowls, etc.
Forming range: 20-32oz, MAX high 105mm,MAX bottom 113mm,MAX top 140mm thickness 150-350gsm
Applicable materials: Mainly PE coated paper，Kraft paper
Machine speed: 80-100pcs/min, speed may fluctuate due to size and thickness reasons
Voltage requirements: 380V-3P
Air pressure requirement: 0.6-0.8mpa, the machine requires an air compressor to supply air，0.4m³/min
Power: 10kw
Machine weight: 3000kgs
Machine size: 2500 1300 1800mm
Packaging size: 2600 1350 1900mm
Cup collection size:950*1000*1850mm
Delivery time: 30-35 days (from the date of receiving the deposit upon confirming the size)
LB 600Y-GP Hydraulic Multifunction Paper Plate Machine adopts straight-line forming, which is paper feeding, forming and collecting in one straight line. stable forming, high efficiency and labor saving.
Our machine has function of automatically complete the full process of die cutting, creasing, embssoing and stack collection. It is an ideal cutting machine
The automatic carton thermoforming machine is a fully automatic paper forming machine with the advantages of high speed and convenient operation. This model uses a self-contained hot air generator for single PE coated paper.
Our LB 1600 Automatic Double Line Paper Box Machine with firm structure,high quality,low noise and high efficiency.1600 Automatic Double Line Paper Box Machine has the full servo control. Besides, it is very fast and suit for paper box of large quantity. It adopts photoelectric system controls. In case of an error in the paper box, the gluing tray will automatically rise, and it will return to normal after one cycle.
LB-1200 Automatic Paper Box Machine is an ideal equipment for the production of carton boxes, such as hamburgers, french fries boxes, fried chicken boxes, children's lunch boxes, take-out boxes, triangular pizza boxes, etc. The structure is sturdy, good quality, low noise, and high efficiency. It has a paper feeding unit, an adjustment unit, a water unit, a forming unit, a finished product collection unit and a counting unit.
